What is included
- One 6108K 8CH PoE NVR
- USB mouse, user manual and listed 52V 2.5A NVR power adapter
- Recording HDD purchased separately
QuarkView 6108K 8CH PoE Network Video Recorder
Record up to eight camera channels with HDMI/VGA display output, H.265 compression, ONVIF camera access and local HDD storage. The listed configuration supplies no recording drive.
QuarkView · XM-6108K
$199
USD
Listed price per package / product; final price and shipping confirmed in the quote.
01 / 01
Model reference image with QuarkView branding
Best fit
- Small wired camera installations
- Up to eight recording positions
Plan your configuration: Choose your preferred option and include any existing equipment, installation needs and delivery destination in your quote.
Model XM-6108K
Channels 8 channels
Compression H.265
Display output HDMI and VGA
Product features
- 8 recording channels
- HDMI/VGA display output
- H.265 compression
- ONVIF camera access
Product overview
Product details
Build an eight-channel recording plan
The current model is the 6108K 8CH recorder. Camera channels, physical powered ports and the PoE power budget are separate limits. Match the camera load and recording settings to the supplied hardware.
Install the recording drive
The No HDD option supplies no recording drive. Install a suitable surveillance HDD, initialise it in the recorder, then check live views, scheduled recording and playback. The listed 14TB maximum is a model reference; it does not determine retention days.
Connect and review
Use HDMI or VGA for a local display. ONVIF provides a path for compatible third-party cameras, while event metadata, audio and advanced controls depend on the camera, firmware and recorder combination. Use the storage and compatibility guides below to plan the installation.
Specifications
Check the details that affect performance.
Prepare your quote with the model, camera quantity, resolution, storage and detection features you need. Include existing equipment and compatibility requirements so we can match the configuration to your installation.
| Model | XM-6108K |
|---|---|
| Channels | 8 channels |
| Compression | H.265 |
| Display output | HDMI and VGA |
| Listed bandwidth | 80M |
| Camera resolution support | 1080P, 3MP, 4MP, 5MP and 8MP |
| Camera protocol | ONVIF |
| Recording modes | Manual, alarm, motion and scheduled |
| Storage | HDD; No HDD configuration |
| Listed maximum HDD | Up to 14TB; match the drive and firmware revision |
Compare listed configurations
Choose your configuration
Compare the listed options. Confirm the exact model and configuration with sales.
- No HDDXM-6108K $199 Request a Quote
Best fit
- Small wired camera installations
- Up to eight recording positions
Before you order
Use these checks to avoid compatibility, storage, and installation surprises.
- Recorder model and camera count
- Recording resolution, frame rate and PoE layout
- HDD option and recording days target
Manuals and App
- QuarkView setup support (opens a new tab)
Use the instructions supplied with the 6108K hardware. The historical 6016K manual is not assigned to this model.
Request a quote
Choose your product and quantity.
This product is already selected. Send the form for a quote, configuration review, and shipping options. Submitting does not place an order.
Need a quick product answer first? Email sales@quarkview.com.
1
Product selected
XM-6108K is carried into the request automatically.
2
Choose the quantity
Buy one system, compare configurations, or prepare a repeat order.
3
Review the quote
Confirm the configuration, shipping, and terms before deciding whether to order.
