What is included
- 4 cameras in the matching base configuration
- 8-channel recorder
- Recording drive: No HDD / 3TB / 4TB
QuarkView 4-Camera PT825D PoE System with 8CH NVR
Pair four PT825D dual-lens cameras with a recorder for near and far viewing at several positions. Select no HDD, 3TB or 4TB storage while keeping the two-lens sensor count separate from recorded output resolution.
QuarkView · 6708KR-4-PT825D-80P-CP1
$299–$448
USD
Listed price per package / product; final price and shipping confirmed in the quote.
01 / 06
Camera reference; system quantity and recording drive are selected separately
Best fit
- Four entrances with near and far viewing tasks
- Small yards and loading bays
- Wired projects needing a recorder and storage choices
Plan your configuration: Choose your preferred option and include any existing equipment, installation needs and delivery destination in your quote.
Model PT825D-80P
Connection Wired PoE
Camera resolution Two lenses labelled 4MP each; 8MP combined sensor count
NVR channels 8
Product features
- PoE Ethernet connection
- Dual-lens picture-in-picture viewing
- Human detection
- Two-way audio
- Infrared and white-light night modes
Product overview
Product details
Pair four PT825D dual-lens cameras with a recorder for near and far viewing at several positions. Select no HDD, 3TB or 4TB storage while keeping the two-lens sensor count separate from recorded output resolution.
A wider scene and a closer view
The PT825D uses two lenses for near and far viewing with picture-in-picture display. Each lens is labelled 4MP. Plan the views around an entrance and its approach rather than treating the combined sensor count as one recorded 4K stream.
Move the view around the scene
Remote pan and tilt changes the direction the camera faces. Human tracking is listed for the camera family. Keep a fixed overview at positions that need uninterrupted coverage.
Choose the night behavior and talk through the camera
A built-in microphone and speaker support two-way talk. Infrared viewing and white-light color modes serve different lighting needs. White illumination is used for the color night view; evaluate the installed view at the actual target distance.
Connect power and plan the recording
Connect each camera to a suitable PoE NVR port or powered switch over Ethernet. The 8CH recorder and supplied camera quantity are separate limits. Size the drive using recorded bitrate and retention needs.
Selected configuration
- 4 cameras in the matching base configuration
- 8-channel recorder
- Recording drive: No HDD / 3TB / 4TB
Setup and software
iCSee handles camera setup and viewing. The recorder manual uses XMEye Pro for NVR access. Camera and recorder connections are separate entries.
Does the 8MP label mean one recorded 4K image?
It describes two lenses labelled 4MP each. It does not establish the pixel dimensions of an individual recorded stream.
Is the zoom a continuous 8X optical lens?
PT825D uses separate near and far lens views. Switching views and enlarging a digital image differ from changing the focal length of a motorized optical lens; no continuous optical-zoom ratio is specified here.
Are the two pictures a stitched panorama?
Picture-in-picture places a smaller view within another view. A stitched panorama and two independent recorded channels are different layouts and are not established by a dual-view display.
Does this camera need Wi-Fi?
No. The listed PoE configuration uses Ethernet for the network connection and a compatible PoE source for power.
What do the recorder channels and camera quantity mean?
The matching base configuration has 4 cameras and a 8-channel recorder. Channel capacity is separate from supplied cameras and physical powered ports.
How long will the hard drive record?
Recording time depends on total recorded bitrate, recording mode and usable drive capacity. Use the storage calculator with your chosen stream settings.
What should be checked with another NVR?
Test saved video, audio, pan/tilt control and the required events independently. Protocol support alone does not establish every function with a third-party recorder.
Practical guides
- Understand dual-lens viewing — Separate two sensors, PiP and stitched output.
- Wide angle and zoom — Compare a scene overview with closer detail.
- Camera and NVR compatibility — Check saved video, audio, controls and events individually.
- Size NVR recording storage — Calculate retention from recorded bitrate and recording mode.
Specifications
Check the details that affect performance.
Prepare your quote with the model, camera quantity, resolution, storage and detection features you need. Include existing equipment and compatibility requirements so we can match the configuration to your installation.
| Model | PT825D-80P |
|---|---|
| Connection | Wired PoE |
| Camera resolution | Two lenses labelled 4MP each; 8MP combined sensor count |
| NVR channels | 8 |
| Camera quantity | 4 |
| HDD options | No HDD / 3TB / 4TB |
| microSD support | Up to 128GB |
| Weather rating | IP66 listed |
| Video codec | H.265 |
| ONVIF | Protocol support listed; feature availability depends on recorder and firmware |
| Audio | Built-in microphone and speaker; two-way talk listed |
Compare listed configurations
Choose your configuration
Compare the listed options. Confirm the exact model and configuration with sales.
- NO HDD · US Warehouse6708KR-4-PT825D-80P-CP1Cameras supplied: 4 · Recording drive: No HDD $299 Request a Quote
- With 3TB HDD · US Warehouse6708KR-4-PT825D-80P-3T-CP1Cameras supplied: 4 · Recording drive: 3TB $388 Request a Quote
- With 4TB HDD · US WarehouseTA-6708KR-4-PT825D-80P-4T-CPCameras supplied: 4 · Recording drive: 4TB $448 Request a Quote
Best fit
- Four entrances with near and far viewing tasks
- Small yards and loading bays
- Wired projects needing a recorder and storage choices
Before you order
Use these checks to avoid compatibility, storage, and installation surprises.
- Viewing distance and mounting height
- Preset patrol or manual control
- Lighting and night-vision expectations
Manuals and App
- PT825 PoE camera family manual — English (PDF) (opens a new tab)
A reference for the listed model family. Match the device label and on-screen interface before following setup steps.
- PoE system family manual — English (PDF) (opens a new tab)
A reference for the listed model family. Match the device label and on-screen interface before following setup steps.
- PoE recorder family manual — English (PDF) (opens a new tab)
A reference for the listed model family. Match the device label and on-screen interface before following setup steps.
- recorder: XMEye Pro — Android (opens a new tab)
- recorder: XMEye Pro — iOS (opens a new tab)
- camera: iCSee — Android (opens a new tab)
- camera: iCSee — iOS (opens a new tab)
- QuarkView setup support (opens a new tab)
Model FAQ
Does the 8MP label mean one recorded 4K image?
It describes two lenses labelled 4MP each. It does not establish the pixel dimensions of an individual recorded stream.
Is the zoom a continuous 8X optical lens?
PT825D uses separate near and far lens views. Switching views and enlarging a digital image differ from changing the focal length of a motorized optical lens; no continuous optical-zoom ratio is specified here.
Are the two pictures a stitched panorama?
Picture-in-picture places a smaller view within another view. A stitched panorama and two independent recorded channels are different layouts and are not established by a dual-view display.
Does this camera need Wi-Fi?
No. The listed PoE configuration uses Ethernet for the network connection and a compatible PoE source for power.
What do the recorder channels and camera quantity mean?
The matching base configuration has 4 cameras and a 8-channel recorder. Channel capacity is separate from supplied cameras and physical powered ports.
How long will the hard drive record?
Recording time depends on total recorded bitrate, recording mode and usable drive capacity. Use the storage calculator with your chosen stream settings.
What should be checked with another NVR?
Test saved video, audio, pan/tilt control and the required events independently. Protocol support alone does not establish every function with a third-party recorder.
